For businesses and institutions seeking a versatile and dynamic communication tool, a modern LED Message Display is the ultimate solution. As a leading provider in Bangladesh, we specialize in supplying and installing the best LED display boards and digital signage systems. A common question we receive is about the led message display board price or digital display board price in Bangladesh.
LED Message Display Board Price & Supplier in Bangladesh | Digital Signage
The cost is not a single figure; it varies based on factors like size, resolution (pixel pitch), whether it’s for indoor or outdoor use, and installation complexity. Whether you need a vibrant outdoor LED message display for advertising, a high-brightness LED notice board for corporate or school announcements, or a versatile digital notice board for real-time information, we offer tailored solutions.
Our services encompass everything from digital display board design and professional installation to providing user-friendly digital signage software for easy content management. Investing in a programmable LED display transforms static notices into captivating visual communication, significantly enhancing engagement. Contact us today for a detailed quote on your LED text display project and see why we are the preferred choice for digital message board solutions across the country.
Product Specification – LED Film Display
Basic Information
- Model No.: KS-ISF-P10-1000×240mm
- Brand / Trademark: KENSUN
- Display Type: LED Video Display (LED Film Screen)
- Pixel Pitch: 10 mm
- Pixel Configuration: 1R, 1G, 1B
- Pixel Density: 10,000 dots/m²
- Scanning Mode: Static Scan
- Brightness: ≥ 4000 nits
- System Operating Platform: Windows XP / Windows 7 / Vista
- Application: Stage Performance, Advertising
- IP Rating: IP65
- Certification: CE, RoHS, FCC
- Life Span: 75,000 – 100,000 Hours
- Cabinet Size: 1000 × 240 mm
- Transport Package: Wooden Case
- Origin: China
- HS Code: 9405600000
- Production Capacity: 100,000 sqm / year
LED Chip Specification
| Color | Type | Brand | Wavelength (λd) | Luminous Intensity (IV) |
|---|---|---|---|---|
| Red | FCOB | Epistar | 620–625 nm | 800–960 mcd |
| Green | FCOB | Epistar | 520–525 nm | 1350–1650 mcd |
| Blue | FCOB | Epistar | 470–475 nm | 330–400 mcd |
LED Module Specification
- Pixel Pitch: 10 mm
- Module Size: 1000 mm (W) × 240 mm (H)
- Module Resolution: 100 × 24 = 2400 dots
- Module Weight: 2 kg
LED Display Cabinet Specification
- Pixel Density: 10,000 dots/m²
- Cabinet Resolution: 100 × 24 = 2400 dots
- Cabinet Dimensions (W × H × D): 1000 × 240 × 20 mm
- Cabinet Material: PCB Board
- Cabinet Weight: 2 kg
- Module Quantity per Cabinet: 1 pc (1W × 1H)
- Frame Frequency: ≥ 60 frames/sec
- Refresh Rate: ≥ 1000 Hz
- Grey Scale: 16-bit
- Color Processing: R(1024) × G(1024) × B(1024)
- Brightness Adjustment: 256 Levels
- Viewing Angle: Horizontal 160°, Vertical 160°
- Nearest Viewing Distance: ≥ 10 meters
- Protection Level (Front/Back): IP43
- MTBF (Mean Time Between Failures): ≥ 5,000 hours
Power & Electrical Parameters
- Input Voltage: AC 110–220V ±10%, 50/60Hz
- Output Voltage: DC 5V (40A / 60A / 80A)
- Power Consumption (Max): 900 W/m²
- Power Consumption (Average): 300 W/m²
Environmental Conditions
- Working Temperature: -30°C to +50°C
- Humidity: 15% – 85%
- Malfunction Dot Rate: < 0.0001
Display Functions
- Text
- Graphics
- Video
Control System Specification
- Control Mode: Synchronization / Asynchronization
- Control System: Sending Card, Receiving Card, Receiving HUB
- PC Operating System: Microsoft Windows 7 / XP / Vista
- Software: ED Studio, Nova, Linsn
- Communication Type: Network Cable, 3G, WiFi (optional)
- Control Card Input: DVI, USB, RJ45, HDMI (optional)
Supported Languages
Chinese, Traditional Chinese, English, French, Japanese, Russian, Thai, Spanish, Polish, Italian, Portuguese, Turkish, Dutch, Greek, Bulgarian, Romanian, Arabic
Product Description – LED Film Screen
The LED Film Screen uses advanced bare LED chip technology integrated onto a high-transparency PCB sheet. Through a special encapsulation process, the display module is embedded into an ultra-thin, high-transmittance optical lens substrate with a thickness of only 1–3 mm.
With a lightweight design of 1–3 kg per square meter, the LED film screen significantly reduces load-bearing pressure on glass, walls, canopies, and other structures. The high transparency rate of up to 90% ensures minimal impact on building aesthetics.
When powered off, the screen seamlessly blends with glass surfaces. When operating, it transforms into a vibrant visual display with high brightness, wide viewing angles, and excellent image clarity, making it ideal for modern advertising and creative display applications.
